| Overall Length: | 40-100mm | Flute: | 1 |
|---|---|---|---|
| Diamond Size: | 0.25mm To 8mm | Feed Velocity: | 1500~5000mm/min |
| Machinable Materials: | Gold,silver,copper,aluminum,acrylic And Other Non-ferrous Metal Material | Optional Material: | Natural Diamond,MCD,CVD,PCD,etc |
| High Light: | Carbide PCD Diamond Cutter,5000mm/min PCD Diamond Cutter,1 Flute Diamond Engraving Tools |
||
PCD Carbide Milling Cutters 45 Degree Angle Cutter PCD Chamfer End Mill
This product is the natural diamond milling cutter produced by our company. The sharp Angle of the cutter can be up to 5 microns. The cutting material of the cutter tip is high-quality natural industrial diamond.
Is suitable for processing of non-ferrous metals (copper, aluminum, zinc, titanium, etc.) as well as the organic board face, the cylindrical part of the mirror effect clear root and light finishing, high-precision tip arc and experienced edge grinding process, the assembly on the CNC machine stability good after cutting board to make the processed surface mirror effect, and finish achieve RA0.2 above, our company production of diamond cutting tools not only high resistance to wear, and use good chip removal performance, is to achieve high efficiency, high brightness, high degree of finish of precision machining preferred.
Our services
1. Customers send detailed inquiry to us by email;
2.We reply with price, specifications, packing, photos, and other details;
3. Both of us agree the price and confirm the details;
4.We write the proforma invoice and send to customers;
5.Customers make deposit;
6.We make mass production samples;
7.We send mass product samples or send photos to customers for approval;
8.Customers confirm the mass production samples;
9.We start mass production.(we have huge stock for most standard end mills);
10. We show ready products' photos or customers inspect on site;
11.Customers make balance payment;
12.Delivery is arranged. Feedback from customers for better work in future.
13.We also make OEM and customized end mills.
(We also do OEM end mills and other coating end milling cutters as you wish)
| Product name | CNC convex side milling Tool |
| Application Apparatus | CNC equipment |
| Optional Material | Natural diamond,MCD,CVD,PCD,etc. |
| Diamond Size | 0.25mm to 8mm |
| Shank Material | Carbide/stainless steel |
| Shank Thickness | 6mm |
| Rotate speed | 10000~30000r/min |
| Feed velocity | 1500~5000mm/min |
|
Machinable materials |
gold,silver,copper,aluminum,acrylic and other Non-ferrous metal material |
|
PCD Recommended Cutting Condition |
|||
| Work piece | Cutting Speed | Depth of Cut | Feed Rate |
| (m/min) | (mm) | (mm/rev) | |
| Aluminum(5~8% SI ) | 350~1600 | 0.05~2.50 | 0.10~0.40 |
| Aluminum(8~12% SI ) | 350~1300 | 0.05~2.50 | 0.10~0.40 |
| Aluminum(14~18% SI ) | 160~800 | 0.05~2.50 | 0.05~0.25 |
| Copper | 350~1000 | 0.15~2.50 | 0.05~0.20 |
| Sintered Carbid | 15~25 | 0.05~0.60 | 0.10~0.20 |
| Glass Fiber | 100~800 | 0.15~0.50 | 0.03~0.25 |
| Carbon | 160~700 | 0.15~2.50 | 0.15~0.40 |
| High Aluminum | 70~250 | 0.05~1.50 | 0.03~0.15 |
| Ceramics | |||
| Wood | 1000-2500 | 0.2~5.0 | 010~0.50 |
We supply service for re-lapping and polishing the diamond tools to increase tool life and performance. The tools can be re-polished about 60-70 times.We have more than 150 trained technicians who can offer fast re-polishing service for diamonds tools.For more details,please contact our sales.
We also provide consultation service in setting up new production line for jewellery making. With about 30 years of experience in the jewellery manufacturing industry. We have rich experience for jewellery making. We have full range of diamond tools that used for jewellery cutting and texturing.
Our technicans will give you valuable suggestions on how to selection the most suitable tool and machines for your company.
Q: Are you Manufacture?
A: Yes, we are manufacture. we produce our “JOEBEN“brand tools for gurantee the quality.
We also trading related tools for customers because we are in these field over 10 years, we are very familiar Chinese market tools. we usually help our customer choose the best suitable related tools for them.
Q: What is your delivery time?
A: Most of models are ex-stock, if out of stock,there usually need about 3-5 days or 7-10 days.
Q: Can you produce non-standard tools?
A: Yes, we can produce non-standard tools as per your drawing.
We also can design tools for you as per your usage requirement
Q: What is your advantages?
A: We are factory who produce our own brand “JOEBEN” tools, we must gurantee our brand quality. Also, we have factory price and fast delivery.
