Carbon Steel Rounded Edge End Mill Corner Radius Milling Cutters U - Groove Design

Carbon Steel Rounded Edge End Mill Corner Radius Milling Cutters U - Groove Design
Carbon Steel Rounded Edge End Mill Corner Radius Milling Cutters U - Groove Design Carbon Steel Rounded Edge End Mill Corner Radius Milling Cutters U - Groove Design

Large Image :  Carbon Steel Rounded Edge End Mill Corner Radius Milling Cutters U - Groove Design

Product Details:
Place of Origin: ShenZhen
Brand Name: Joeben
Certification: ISO9001:2015 , GR201744202646
Model Number: REEM11
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece/Pieces
Price: negotiable
Packaging Details: 1.White parts for protect the flute of cutter 2.One plastic pipe packs one piece 3.Use air bubble paper toto encase the plastic pipes 4.Put goods encased with air bubble paper into the carton box 5. Inner box/carton/palle
Delivery Time: 3-5work days
Payment Terms: L/C, T/T, D/A,
Supply Ability: 100000 Piece/Pieces per Month
Detailed Product Description
Overall Length: 50-100mm Diameter: D1-20MM
Suitable For: Carbon Steel Precision: High Precision
Application: CNC Process Workpiece: Aluminum, Acrylic
High Light:

bull nose milling cutter

,

carbide corner rounding cutter

Rounded Edge End Mill hot sale milling cutters corner radius rounding carbide end millCarbon Steel Rounded Edge End Mill Corner Radius Milling Cutters U - Groove Design 0

overview



    Non-uniform U groove design makes the chip removal space larger and smoother, suitable for large feed cavity processing, end edge insert milling processing.Finish, no Yin and Yang, vibration lines, bright line.

1, try to use the feed per blade, so as to get the cutting position when the chip thickness, so as to reduce tool wear.The front Angle grooved indexable blade is used to obtain smooth cutting power.

2, choose suitable for the width of the workpiece tool diameter.

3, choose the appropriate main Angle.

4. Place each cutter in an orderly manner.

5. Follow the rules of tool maintenance and repair, and monitor tool wear.



   Extremely fine diamond material with high hardness can effectively cut burr, u-groove design at blade, large front Angle, effectively reduce cutting resistance, facilitate smooth chip removal and improve working efficiency under high precision.Welcome to choose Chopin cutter.With toughness superhard abrasive machining hard and hard, hard machining the minimal consumption, can be directly below 50 degrees for heat treatment of materials for the rough machining to fine processing, reduce the changeover times, saves the production schedules, stable and reliable, and chip removal is fast, and can be a long time to maintain its sharpness and abrasive tool shape, can not only guarantee the accuracy of the workpiece, and greatly improve the machining efficiency, and solve the problem of environmental pollution.



HRC45 HRC55 HRC60 HRC65
YG10X YG10.2 &WF25 Germany K44 & K40 H10F
Grain Size:0.7um
Co:10 %
Flexural strength:3320N/mm2
Grain Size:0.6um
Co:10 %
Flexural strength:4000N/mm2
Grain Size:0.5um
Co:12 %
Flexural strength:4300N/mm2
Grain Size:0.5um
Co:10 %
Flexural strength:4300N/mm2





d R D L flute
4 0.2/0.3/0.5/1.0 4 50 4
4 0.2/0.3/0.5/1.0 4 75 4
6 0.2/0.3/0.5/1.0 6 50 4
6 0.2/0.3/0.5/1.0 6 75 4
8 0.5/1.1/1.5/2.0 8 60 4
10 0.5/1.1/1.5/2.0 10 100 4
12 0.5/1.1/1.5/2.0 12 75 4
12 0.5/1.1/1.5/2.0 12 100 4
16 0.5/1.1/1.5/2.0 16 100 4





EDP No. Dia(mm) Corner R Flute Length(mm) Effective Length(mm) Flutes Shank Dia(mm) Coating
1 1.0 0.2 3 8 4 4 Customized
2 2.0 0.2 6 12 4 4 Customized
3 3.0 0.50 8 15 4 4 Customized
4 4.0 0.5 6 15 4 6 Customized
5 6.0 0.5 9 18 4 6 Customized
6 6.0 0.5 4.8 12 4 6 Customized



Product composition:Tungsten steelF-ED-001 end mill Features

1. Suitable for aluminum alloy (≤ 65 HRC)

2. High performance alcr series coating,high temperature resistance and high wear resistance.

3. Adapt to several kinds of cooling conditions, for example oil mist, water, oil, air

Carbon Steel Rounded Edge End Mill Corner Radius Milling Cutters U - Groove Design 1

Q:Are you Manufacture?

A:Yes, we are manufacture. we produce our “JOEBEN “brand tools for gurantee the quality.

We also trading related tools for customers because we are in these field over 10 years, we are very familiar Chinese market tools. we usually help our customer choose the best suitable related tools for them.

Q: What is your delivery time?

A: Most of models are ex-stock, if out of stock,there usually need about 3-5 days or 7-10 days.

Q: Can you produce non-standard tools?

A: Yes, we can produce non-standard tools as per your drawing.

We also can design tools for you as per your usage requirement

Q:What is your advantages?

A: We are factory who produce our own brand tools, we must gurantee our brand quality. Also, we have factory price and fast delivery.



Our advantage:

  • 1. 10 years experience in carbide roll and cutting tool manufacturing
  • 2. From row material to tool produdtion.
  • 3. World top level prodution equipment and rich experience team

ATTACTION:

  • 1.Make sure work piece and machine are stable and use a precision holder.
  • 2.Please adjust the speed,feed and cutting depth according to actual cutting conditions.
  • 3.The milling conditions are for an end mill where the tool overhang length is less than 4 D(mill diameter). When the tool overhang length is longer, please adjust the speed,feed and cutting depth.
