Stainless Steel Rounded Edge End Mill 3 Flute Carbide End Mills Anti - Breakage Edge

Stainless Steel Rounded Edge End Mill 3 Flute Carbide End Mills Anti - Breakage Edge
Stainless Steel Rounded Edge End Mill 3 Flute Carbide End Mills Anti - Breakage Edge Stainless Steel Rounded Edge End Mill 3 Flute Carbide End Mills Anti - Breakage Edge Stainless Steel Rounded Edge End Mill 3 Flute Carbide End Mills Anti - Breakage Edge

Large Image :  Stainless Steel Rounded Edge End Mill 3 Flute Carbide End Mills Anti - Breakage Edge

Product Details:
Place of Origin: ShenZhen
Brand Name: Joeben
Certification: ISO9001:2015 , GR201744202646
Model Number: EMC08
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece/Pieces
Price: negotiable
Packaging Details: 1.White parts for protect the flute of cutter 2.One plastic pipe packs one piece 3.Use air bubble paper toto encase the plastic pipes 4.Put goods encased with air bubble paper into the carton box 5. Inner box/carton/palle
Delivery Time: 3-5work days
Payment Terms: L/C, T/T, D/A,
Supply Ability: 100000 Piece/Pieces per Month
Detailed Product Description
Place Of Origin: Guangdong, China (Mainland) Overall Length: 50-10mm
Diameter: D1-20MM Processing Type: Metal Cutting Tools
Name Of The Cutting Tool: End Mill Cutter Coating: NOT
High Light:

corner rounding milling cutters

,

bull nose milling cutter

CNC End Mill Cutter For Stainless Steel 3 Flute Solid Carbide Drilling End Mills

Stainless Steel Rounded Edge End Mill 3 Flute Carbide End Mills Anti - Breakage Edge 0

overview

F-ED-001 end mill Features:

1. Suitable for steels & cast iron (≤ 65 HRC)

2. High performance alcr series coating,high temperature resistance and high wear resistance.

3. Adapt to several kinds of cooling conditions, for example oil mist, water, oil, air cooling.

End Mill Tool material composition:

1. Physical Properties:

   a. Hardness greater than or equal to 92.6 HRA;

   b. Density greater than or equal to 14.4g/cm³;

   c. TRS greater than or equal to 3800 N/mm²;

   d. Free of ETA phase condition;

   e. No contamination by other materials;

   f. Porosity = A02/ B00 / C00 ;

   g. Uniform and consistent grain size. No grain size can be larger than specified.

   h. Chromium carbide grain growth inhibitor only.

2. All the tools of production, coatings are used in Germany, Switzerland, processing equipment;

3. It's proposed cutting less than 65HRC;

       Adopt new fine grain tungsten steel material has high wear resistance and strength, to belong to high hardness, high speed cutting application of universal milling cutter, can on heat treatment of materials directly under 60 ° the rough machining to finish machining, reduce the changeover times, improve efficiency, save the schedule.2 blade cutting groove is given priority to, 4 blade with lateral milling and face milling is given priority to, suggested that cutting HRC60 ° within the steel material.

        In order to obtain a better cutting surface and prolong the life of the milling cutter, it is necessary to use a tool handle with high precision, high rigidity and good dynamic balance.

Before using the milling cutter, please test the tool deflection. If the accuracy is more than 0.01mm, please correct it before cutting



  The shorter the length of the cutter extension chuck, the better. If the extension is longer, please adjust the speed, feed speed or cutting amount by yourself

Suitable for hrc30-52 metal workpiece, the workpiece surface finish is better, the processing material versatility is wider, it is recommended to use high rigidity, high precision tool handle and barrel clip, comprehensive pulsation control within 0.005mm.Smooth chip removal design, enhance damage resistance, improve the processing surface finish,

    Selects fine grain quality bar, processing imported five axis tool grinding machine, cutting tool inspection standard strictly, to ensure the consistency of the cutter size and beat high temperature wear resistance, and both hardness and toughness, suitable for 63 ° hard steel, hardened steel, aluminum, copper and other materials, under the condition of the bits ensure the space, the big core diameter design, greatly enhance the tool rigidity and vibration resistance, reduce the cutting knife, prolong service life.Through passivation technology, the tool adhesion particles are completely removed, the edge passivation, processing high hardness material is more convenient, anti-breakage edge, prolong the service life of the tool.

Sharp blade, irregular special new thin blade sharp while ensuring the durable wear of the tool.




Tungsten Carbide Flat Endmill, Square End Mill Cutting Tools For Metal(Standard Type)
Machining Range:AL5052,AL6063,AL6061,AL7075
EDP NO. Diameter Flute Length Flute O.AL Shank Dia
2102010581 1.0 3 4 50 4
2102010756 1.5 4.5 4 50 4
2102010580 2.0 6

4

50 4
2113010429 2.5 7.5 4 50 4
2102010384 3.0 9 4 50 4
2102010595 4.0 12 4 50 4
2113010430 5.0 15 4 50 6
2113010431 6.0 18 4 50 6
2113010432 8.0 24 4 60 8
2113010433 10.0 30 4 75 10
2113010434 12.0 36 4 75 12


Stainless Steel Rounded Edge End Mill 3 Flute Carbide End Mills Anti - Breakage Edge 1

Stainless Steel Rounded Edge End Mill 3 Flute Carbide End Mills Anti - Breakage Edge 2



Q:Are you Manufacture?

A:Yes, we are manufacture. we produce our “JOEBEN “brand tools for gurantee the quality.

We also trading related tools for customers because we are in these field over 10 years, we are very familiar Chinese market tools. we usually help our customer choose the best suitable related tools for them.

Q: What is your delivery time?

A: Most of models are ex-stock, if out of stock,there usually need about 3-5 days or 7-10 days.

Q: Can you produce non-standard tools?

A: Yes, we can produce non-standard tools as per your drawing.

We also can design tools for you as per your usage requirement

Q:What is your advantages?

A: We are factory who produce our own brand “JOEBEN” tools, we must gurantee our  brand quality. Also, we have factory price and fast delivery.



Our advantage:

  • 1. 10 years experience in carbide roll and cutting tool manufacturing
  • 2. From row material to tool produdtion.
  • 3. World top level prodution equipment and rich experience team

ATTACTION:

  • 1.Make sure work piece and machine are stable and use a precision holder.
  • 2.Please adjust the speed,feed and cutting depth according to actual cutting conditions.
  • 3.The milling conditions are for an end mill where the tool overhang length is less than 4*D(mill diameter). When the tool overhang length is longer, please adjust the speed,feed and cutting depth.
