Payment & Shipping Terms:
|Diameter:||D2-20MM||Other Service:||OEM/ODM Or Custom-made|
|Material:||Carbide, Single Crystal Diamond (PCD)||Precision:||High Precision|
|Keywords:||PCD Tool, Insert Cutting Tool,PCD Cutting Tool||Suitable For:||Acrylic, PVC, PC, PET, PMMA, Gold, Silver|
|Shank Diameter:||6mm/8mm/10mm/12mm||DELIVERY TIME:||3-7 Working Days|
|Types Of CNC Cutting Tools:||Single Flute /Two Flutes|
30 degree pcd milling cutter,
cnc router pcd milling cutter,
35 degree cnc router end mill
This product is a natural diamond high-gloss mirror turning tool produced by our company. The cutting material of the tool tip is high-quality natural industrial diamond. It is suitable for processing non-ferrous metals (copper, aluminum, zinc, titanium, etc.) Mirror turning processing, high-precision tool nose arc and experienced cutting edge grinding process, after being assembled on a CNC machine tool with good stability, the machined surface of the workpiece can produce a mirror effect, and the finish can reach RA0.1.
The diamond cutting tools produced by our company not only have strong wear resistance, but also have good chip removal performance. They are the first choice for precision machining with high efficiency, high brightness and high finish.
The high-quality natural diamond is selected, and the natural diamond single crystal is welded to the tool shank by a special welding process. It is made by special geometric angle design and sharpening technology. According to customer requirements, it can be processed into various angles and radians. It is mainly used for aspheric and free optical surface processing, Wiener processing, ultra-precision processing, etc.
PCD diamond tools: Natural diamonds are expensive, and polycrystalline diamond (PCD) is widely used in cutting. Since the early 1970s, polycrystalline diamond (Polycrystauine diamond, referred to as PCD for short) has been successfully developed using high temperature and high pressure synthesis technology. Since then, natural diamond tools have been replaced by artificial polycrystalline diamond in many occasions. PCD raw materials are rich in sources, and its price is only one tenth to one tenth of natural diamond. PCD tools cannot grind extremely sharp edges However, the surface quality of the processed workpiece is not as good as that which can be naturally used for fine cutting of non-ferrous metals and non-metals, and it is difficult to achieve ultra-precision mirror cutting.
The PCD polycrystalline diamond rough polishing knife and the ND natural diamond fine (fine) polishing knife are sequentially clamped in a special polishing cutter head, which can be used for acrylic polishing in diamond polishing machines, edge grinding machines, numerical control centers (CNC) or milling machines and other equipment. Plate, rough and fine polishing at one time.
The tool is composed of natural diamond (PCD) fine polishing knife, which has good polishing effect and fine texture. The tool grinding process is mature and the chip removal performance is excellent, and it can complete the polishing of dozens of sheets at one time.
1. Make according to customer's samples, drawings and instructions to improve cooperation efficiency and accuracy.
2. The specific use requirements of customers should be clearly communicated with our company's technical staff. We recommend suitable products according to your specific situation, and reduce costs while ensuring product performance.
3. The quality, size and difficulty of the production process of the diamond determine the price of the product, the structure of the diamond determines the performance of the product, and the structure of the handle body is made according to the installation requirements of the machine tool, so please choose your needs reasonably.
|Product Name||PCD/CBN/MCD/ND Inserts High Quality Diamond Inserts|
|Type||PCD/ MCD/ ND/ CVD/ CBN|
|Features||No burs, high precision, good surface effects and high cutting efficiency and long work time|
|Advantages||Factory direct sales, short delivery time; non-standard customization, quality assurance; attentive service, customer first|
|Welcome and congratulations!You found us a professional factory!|
|Size & Design||
1.We not only supply all kinds of high quality solid carbide turning tool ,but
also different types of Drill Bits,Reamers,Tool Holders,Cutter Heads,Saw
Blades and Milling cutter,There are diamond grinding wheel, diamond dressing tools and hardness head.
2. We have 0.02mm-25mm different diameter and 38mm-150mm length
Milling Cutters for your winner market.HRC45/55/60/65 ,1-6 flutes for you
3.OEM:Special Cutters Customized acceptable!Coated OEM also.We can
produceaccording to your drawing,too.Or the hot deisgned recommend
|4. HS Code reference for you to control everything:8207709000.|
|5. Mixed size and types in one batch available.|
|6. For distributor,we can label your brands on cutters and plastic box.|
1. We accept Mix coated in the same model number, Also one batch with
different coating and types.
|2. AlTiN,TiAlN,TiSiN,TiN,DLC,NANO for you to choose to win your competitors!|
|MOQ (Small Qty )||5-10-500-1000-5000-10000 pcs all are welcome. 5 pieces per order is MOQ.|
We package all our goods carefully.We also accept your packing design OEM
packing it for your control.
|Samples Service||1. Some items free samples for you.|
|2. Free samples but pay shipping cost.|
|3. Lowest shiping fee for you to choose.|
|4. Order to us,sample fee will be refund to you.|
|5. Become our VIP clients,free samples for you!|
|6.OEM samples are hot welcome.|
Q:Are you Manufacture?
A:Yes, we are manufacture. we produce our “JOEBEN “brand tools for gurantee the quality.
We also trading related tools for customers because we are in these field over 10 years, we are very familiar Chinese market tools. we usually help our customer choose the best suitable related tools for them.
Q: What is your delivery time?
A: Most of models are ex-stock, if out of stock,there usually need about 3-5 days or 7-10 days.
Q: Can you produce non-standard tools?
A: Yes, we can produce non-standard tools as per your drawing.
We also can design tools for you as per your usage requirement
Q:What is your advantages?
A: We are factory who produce our own brand “JOEBEN” tools, we must gurantee our brand quality. Also, we have factory price and fast delivery.
