Product Details:
Payment & Shipping Terms:
|
| Suitable For: | Gold/Silve/Aluminum/Brass/Acrylic/Plastic/PVC/MDF | OEM: | Acceptable |
|---|---|---|---|
| DELIVERY TIME: | 3-7 Working Days | Transport: | TNT\DHL\ Fedex\ EMS\ UPS |
| Application: | Contact Lens, Glasses, Metal Mirror | Usage: | Aluminum, Copper, Bronze, Brass, Green Tungsten Carbide |
| High Light: | CBN insert cnc turning,WNGA 080404 insert cnc turning |
||
overview
Folding has high thermal stability and high temperature hardness
The heat resistance of CBN can reach 1400~1500℃, and the hardness is the normal temperature hardness of Al2O3/TiC ceramics at 800℃. Therefore, when the cutting temperature is higher, the processed material will be softened, and the hardness difference between the tool will increase, which is conducive to the cutting process, and the tool life will not be affected.
Folding has high chemical stability
CBN has a high antioxidant capacity, no oxidation phenomenon at 1000 ° C, and iron materials at 1200~1300 ° C does not occur chemical reaction, but at 1000 ° C will produce hydrolysis with water, resulting in a large number of CBN wear, so with PCBN tool wet cutting need to pay attention to select the type of cutting fluid. Under normal circumstances, wet cutting does not significantly improve the life of PCBN tools, so dry cutting is often used when using PCBN tools.
Folding has good thermal conductivity
The thermal conductivity of CBN material is lower than diamond but much higher than carbide, and with the improvement of cutting temperature, the thermal conductivity of PCBN tool continues to increase, so that the heat at the tip of the tool can be quickly transmitted, which is conducive to the improvement of workpiece processing accuracy.
Folding has a low coefficient of friction
The coefficient of friction between CBN and different materials is between 0.1 and 0.3, which is much lower than the coefficient of friction of cemented carbide (0.4 to 0.6), and it decreases slightly with the increase of friction speed and positive pressure. Therefore, the low friction coefficient and excellent anti-bonding ability make it difficult to form a retention layer or chip nodules when cutting CBN tools, which is conducive to improving the quality of the machined surface.
Folding is suitable for high-speed and ultra-high-speed cutting technology
PCBN tools are most suitable for high-speed cutting of cast iron, hardened steel and other materials. From the PCBN tool cutting cast iron and hardened steel tool back tool wear and cutting distance relationship can be seen: when the cutting speed exceeds a certain limit, the higher the cutting speed, PCBN tool back tool wear speed is smaller, that is, high-speed cutting tool life is higher, this feature is especially suitable for modern high-speed cutting processing.
| MCD Recommended Cutting Condition | |||
| Work piece | Cutting Speed | Depth of Cut | Feed Rate |
| (m/min) | (mm) | (mm/rev) | |
| Aluminum(5~8% SI ) | 350~1600 | 0.05~2.50 | 0.10~0.40 |
| Aluminum(8~12% SI ) | 350~1300 | 0.05~2.50 | 0.10~0.40 |
| Aluminum(14~18% SI ) | 160~800 | 0.05~2.50 | 0.05~0.25 |
| Copper | 350~1000 | 0.15~2.50 | 0.05~0.20 |
| Sintered Carbid | 15~25 | 0.05~0.60 | 0.10~0.20 |
| Glass Fiber | 100~800 | 0.15~0.50 | 0.03~0.25 |
| Carbon | 160~700 | 0.15~2.50 | 0.15~0.40 |
| High Aluminum | 70~250 | 0.05~1.50 | 0.03~0.15 |
| Ceramics | |||
| Wood | 1000-2500 | 0.2~5.0 | 010~0.50 |
| Grade | Work-piece material | Hardness | V(m/min) | F(mm/rev) | Ap(mm) |
| CBN | Gray cast iron | HB170-300 | 500-1500 | 0.1-0.4 | 0.1-1.5 |
| Nodular cast iron | HB240-300 | 200-400 | 0.1-0.4 | 0.1-0.5 | |
| Alloyed cast iron | HB240-300 | 150-300 | 0.05-0.4 | 0.1-0.5 | |
| Fe-based P/M | HRC45-50 | 50-150 | 0.05-0.4 | 0.05-0.5 | |
| Hardened steels | HRC55-65 | 80-200 | 0.05-0.2 | 0.05-0.2 | |
| Heat-resistant alloys | 50-200 | 0.05-0.2 | 0.05-0.2 | ||
| PCD | AI and AI alloys | 200-3000 | 0.05-0.5 | 0.05-1.0 | |
| Non-mentals Cemented | 100-500 | 0.05-0.5 | 0.05-1.0 | ||
| Carbide | 20-30 | 0.05-0.2 | 0.05-0.2 |
| Product Name | PCD/CBN/MCD/ND Inserts High Quality Diamond Inserts |
| Suitable Material | Gold/Silve/Aluminum/Brass/Acrylic/Plastic/PVC/MDF/Steel |
| Type | PCD/ MCD/ ND/ CVD/ CBN |
| Features | No burs, high precision, good surface effects and high cutting efficiency and long work time |
| Advantages | Factory direct sales, short delivery time; non-standard customization, quality assurance; attentive service, customer first |
| Brand | Joeben |
| Material | CBN, PCBN, Carbide |
| OEM/ODM | Acceptalbe |
| Manufacture | Yes |
| No of Edge | 4 |
| Cutting Material | Hardened steel, cast iron, HSS roll, sintered metal, high hardness mat |
| Package | 1pc/5pcs/10pcs per plastic box |
| MOQ | 2pcs |
| Delivery Time | 7-10 days |
| Advantage | Durable, Excellent surface finish, Reduce the cost |
Q:Are you Manufacture?
A:Yes, we are manufacture. we produce our “JOEBEN “brand tools for gurantee the quality.
We also trading related tools for customers because we are in these field over 10 years, we are very familiar Chinese market tools. we usually help our customer choose the best suitable related tools for them.
Q: What is your delivery time?
A: Most of models are ex-stock, if out of stock,there usually need about 3-5 days or 7-10 days.
Q: Can you produce non-standard tools?
A: Yes, we can produce non-standard tools as per your drawing.
We also can design tools for you as per your usage requirement
Q:What is your advantages?
A: We are factory who produce our own brand “JOEBEN” tools, we must gurantee our brand quality. Also, we have factory price and fast delivery.
