2 Flutes Carbide Ball End Mill Tungsten Tapered Ball Nose End Mill Wear Resistance

2 Flutes Carbide Ball End Mill Tungsten Tapered Ball Nose End Mill Wear Resistance
2 Flutes Carbide Ball End Mill Tungsten Tapered Ball Nose End Mill Wear Resistance 2 Flutes Carbide Ball End Mill Tungsten Tapered Ball Nose End Mill Wear Resistance 2 Flutes Carbide Ball End Mill Tungsten Tapered Ball Nose End Mill Wear Resistance

Large Image :  2 Flutes Carbide Ball End Mill Tungsten Tapered Ball Nose End Mill Wear Resistance

Product Details:
Place of Origin: ShenZhen
Brand Name: Joeben
Certification: ISO9001:2015 , GR201744202646
Model Number: BEM18
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece/Pieces
Price: negotiable
Packaging Details: 1.White parts for protect the flute of cutter 2.One plastic pipe packs one piece 3.Use air bubble paper toto encase the plastic pipes 4.Put goods encased with air bubble paper into the carton box 5. Inner box/carton/palle
Delivery Time: 3-5work days
Payment Terms: L/C, T/T, D/A,
Supply Ability: 100000 Piece/Pieces per Month
Detailed Product Description
Diameter: D2-20MM Other Service: OEM/ODM Or Custom-made
Workpiece: Aluminum, Acrylic Overall Length: 50-100mm
Certification: ISO&SGS Sample Order: Accepted
High Light:

ball nose end mill cutter

,

2 flute ball nose end mill

Carbide Ball End Mill 2 Flutes Tungsten Carbide taper neck ball nose End Mill Cutter/carbide End mills

2 Flutes Carbide Ball End Mill Tungsten Tapered Ball Nose End Mill Wear Resistance 0

overview

1. Fully enables running at rough machining parameters, resulting in finish surface quality.
2. Excellent performance in machining titanium, stainless steel and high temperature alloys.
3. The coating provides longer tool-life or increased cutting-values.
4. Suitable for all types of steel or metal.

Original raw micro grain material, high hardness and T.R.S

a, Material: tungsten carbide
b, TRS: >3600 N/mm2
c, HRA: 91.8-92.4, HRC:45/55/60/65
d, Grain size: 0.2-0.6μm
e, Helix angle: 30°-45 °

Diameter of cutting edge: 0.2-0.9mm; 1-20mm

Size: Diameter 1.0mm-20mm standard and non-standard.

Cutting Form: Square,Ball nose, Corner Radius, Taper Flute, etc.

Type of flute: 2/3/4

Other products: Drills,reamer, tool holders, ER collet, boring cutters, carbide inserts, cutter heads,etc.

【introduction 】usually three or four blade and multi-blade, mainly used for CNC, computer gongs, precision carving machine, CNC lathe, automatic lathe or other machine tools on the workpiece precision machining tools.It features high machining efficiency, fast machining speed, high machining accuracy, good surface roughness of workpiece, high chip conductivity, high feed, long service time, etc. It is suitable for dry cutting and cooling cutting.

Blade diameter X blade length (blade height/blade thickness/blade width) X air-proof length

1. This type of milling cutter is for aluminum alloy processing, has 2 / 3 flutes, flat and ball nose, without coating.
2. As the aluminum is softer, require high speed cutting. And our end mills for aluminum is single margin design, edge-line is very sharp, coating will make it dull. Besides, coating will lead to sticking to the cutters.
3. Milling cutter for aluminum owned good chipping discharge, suitable for high speed and large scale cutting.

Flute Diameter Flute Length Shank Diameter Total Length R Flutes
1 2 4 50 0.5 2
1.5 3 4 50 0.75 2
2 4 4 50 1 2
2.52 5 4 50 1.25 2
3 6 4 50 1.5 2
3 6 4 50 1.5 2
4 8 4 50 2 2
5 10 5 50 2.5 2
5 10 6 50 2.5 2
6 12 6 50 3 2
7 14 8 60 3.5 2
8 16 8 60 4 2
4 8 4 75 2 2
6 12 6 75 3 2
8 16 8 75 4 2
9 18 10 75 4.5 2
10 20 10 75 5 2
12 24 12 75 6 2
4 8 4 100 2 2
6 12 6 100 3 2
8 16 8 100 4 2
10 20 10 100 5 2
12 24 12 100 6 2
14 28 14 100 7 2
16 32 16 100 8 2
18 36 18 100 9 2
20 40 20 100 10 2
HRC45 HRC55 HRC60 HRC65
YG10X YG10.2 &WF25 Germany K44 & K40 H10F
Grain Size:0.7um
Co:10 %
Flexural strength:3320N/mm2
Grain Size:0.6um
Co:10 %
Flexural strength:4000N/mm2
Grain Size:0.5um
Co:12 %
Flexural strength:4300N/mm2
Grain Size:0.5um
Co:10 %
Flexural strength:4300N/mm2



F-ED-001 end mill Features:

1. Suitable for aluminum alloy (≤ 65 HRC)

2. High performance alcr series coating,high temperature resistance and high wear resistance.

3. Adapt to several kinds of cooling conditions, for example oil mist, water, oil, air cooling.

End Mill Tool material composition:

1. Physical Properties:

a. Hardness greater than or equal to 92.6 HRA;

b. Density greater than or equal to 14.4g/cm³;

c. TRS greater than or equal to 3800 N/mm²;

d. Free of ETA phase condition;

e. No contamination by other materials;

f. Porosity = A02/ B00 / C00 ;

g. Uniform and consistent grain size. No grain size can be larger than specified.

h. Chromium carbide grain growth inhibitor only.

2. All the tools of production, coatings are used in Germany, Switzerland, processing equipment;

3. It's proposed cutting less than 65HRC;



  • Other Service:  OEM/ODM or custom-made
  • Machining parts:Outer circle and inner circle of turning parts
  • Product composition:Tungsten steel

2 Flutes Carbide Ball End Mill Tungsten Tapered Ball Nose End Mill Wear Resistance 1

Q:Are you Manufacture?

A:Yes, we are manufacture. we produce our “JOEBEN “brand tools for gurantee the quality.

We also trading related tools for customers because we are in these field over 10 years, we are very familiar Chinese market tools. we usually help our customer choose the best suitable related tools for them.

Q: What is your delivery time?

A: Most of models are ex-stock, if out of stock,there usually need about 3-5 days or 7-10 days.

Q: Can you produce non-standard tools?

A: Yes, we can produce non-standard tools as per your drawing.

We also can design tools for you as per your usage requirement

Q:What is your advantages?

A: We are factory who produce our own brand “JOEBEN” tools, we must gurantee our brand quality. Also, we have factory price and fast delivery.



Our advantage:

  • 1. 10 years experience in carbide roll and cutting tool manufacturing
  • 2. From row material to tool produdtion.
  • 3. World top level prodution equipment and rich experience team

ATTACTION:

  • 1.Make sure work piece and machine are stable and use a precision holder.
  • 2.Please adjust the speed,feed and cutting depth according to actual cutting conditions.
  • 3.The milling conditions are for an end mill where the tool overhang length is less than 4*D(mill diameter). When the tool overhang length is longer, please adjust the speed,feed and cutting depth.
